• Company Profile
    Shanghai XK Construction Material Co.,Ltd

    Established in 1997 to support cabling system.XK has grown to become one of the largest Building Material manufacturers in Shanghai, china.


    Our main products includes: cable trunking, cable tray,cable ladder,wire mesh cable tray, electrical conduit, strut channel and fittings that in accordance with BS, UL,CE,NEMA, AMSI, JIS and GB standard, are widely used in the markets, hotels, power plant, underground construction and mansion. Etc.


    Our base of high quality and competitive price have allowed XK to experience tremendous growth and rapid expansion which is still ongoing today. We look forward to making the impossible happen for you. Our products have been mainly exported to Russia, Korea, Japan, Saudi Arabia, United States, Australia, etc. XK is always dedicating to the development of international market and offering professional service to the clients.

    The principle of Quality First, Service First, Integrity First, which keeps XK moving forward progressively. XK looking forward to establishing a long-friendly relationship with all of you.

  • Produce Ability
    Shanghai XK Construction Material Co.,Ltd
    • Automatic Process line
    • XK Cable Tray
    • XK Electric Conduit
    • XK Strut Channel

    Parameter

    Model

    Motor Power

    Thickness

    Type

    Speed

    Control

    XK-100-400
    Cable Tray Machine

    30KW

    0.5-1.8mm

    100x50-400x100

    8-12m/min

    Automatic adjustment width and height

    XK-50-100
    Cable Tray Machine

    17.5KW

    0.3-1.5mm

    50x50,100x50

    10-15m/min

    Automatic punching ,encoder  controls length

    XK-50-200
    Cover Machine

    5.5KW

    0.3-1.2mm

    50,100,150,200

    30-40m/min

    High speed tracking cut,

    XK-200-600
    Cover Machine

    20KW

    0.5-2mm

    200-600

    8-12m/min

    Automatic adjustment of width


    Process Flow:
    Coiler —Flatting— Punching —Roll Forming —Cutting —Finishing

    Type

    Size

    W(mm)

    H(mm)

    Thickness (mm)

    L(mm)

    Cable Tray

    XK-CT-1

    100*50

    100

    50-200

    0.6-2.5

    2000-6000

    XK-CT-2

    200*60

    200

    50-200

    0.6-2.5

    2000-6000

    XK-CT-3

    400*70

    400

    50-200

    0.6-2.5

    2000-6000

    XK-CT-4

    500*80

    500

    50-200

    0.6-2.5

    2000-6000

    XK-CT-5

    600*90

    600

    50-200

    0.6-2.5

    2000-6000

    XK-CT-6

    800*100

    800

    50-200

    0.6-2.5

    2000-6000

    XK-CT-7

    1000*150

    1000

    50-200

    0.6-2.5

    2000-6000


    Cable Trunking

    XK-CT-8

    100*50

    100

    50-200

    0.6-2.5

    2000-6000

    XK-CT-9

    300*60

    300

    50-200

    0.6-2.5

    2000-6000

    XK-CT-10

    500*70

    500

    50-200

    0.6-2.5

    2000-6000

    XK-CT-11

    700*80

    700

    50-200

    0.6-2.5

    2000-6000

    XK-CT-12

    800*90

    800

    50-200

    0.6-2.5

    2000-6000

    XK-CT-13

    1000*100

    1000

    50-200

    0.6-2.5

    2000-6000

    Cable  Ladder

    XK-CL-1

    100*50

    100

    50-200

    0.6-2.5

    2000-6000

    XK-CL-2

    200*60

    200

    50-200

    0.6-2.5

    2000-6000

    XK-CL-3

    300*80

    300

    50-200

    0.6-2.5

    2000-6000

    XK-CL-4

    500*100

    500

    50-200

    0.6-2.5

    2000-6000

    XK-CL-5

    600*150

    600

    50-200

    0.6-2.5

    2000-6000

    XK-CL-6

    700*160

    700

    50-200

    0.6-2.5

    2000-6000

    XK-CL-7

    800*180

    800

    50-200

    0.6-2.5

    2000-6000

    XK-CL-8

    1000*200

    1000

    50-200

    0.6-2.5

    2000-6000

    Wire Mesh

    XK-WM-1

    50*80

    50

    25-200

    /

    3000

    XK-WM-2

    100*80

    100

    25-200

    /

    3000

    XK-WM-3

    150*80

    150

    25-200

    /

    3000

    XK-WM-4

    200*80

    200

    25-200

    /

    3000

    XK-WM-5

    250*80

    250

    25-200

    /

    3000

    XK-WM-6

    300*80

    300

    25-200

    /

    3000


    Note:

    1.Width  size must be 50 times the number.

    2. Customers can choose according to their own needs high; wide; long, single width size must be a multiple of 50, the length of the size must be a multiple of 100.

    3.Special requirements can be customized.

    Remark:
    * Size can be customized of Cable Tray,Cable Trunking,Cable Ladder
    * Materials can be used Zinc Steel Plate ;Stainless Steel S201,S304,S316 ;Aluminum
    * Finish: Pre -galvanized ;Hot Dip Galvanized ;Powder Coated & Fire Proof


    XK Electrical Conduit Series List
    BS4568-1970


    Size (mm)

    OD(mm)

    T (mm)

    Thread Length (mm)

    Weight (KG/m)

    Class Three

    Class Four

    Min

    Max

    Min

    Max

    Min

    Max

    Min

    Max

    16

    15.7

    16

    1.4±0.10

    11.5

    13.5

    0.452

    0.531

    0.483

    0.594

    20

    19.7

    20

    1.6±0.15

    13.0

    15.0

    0.643

    0.783

    0.682

    0.862

    25

    24.6

    25

    1.6±0.15

    16.0

    18.0

    0.811

    0.995

    0.860

    1.095

    32

    31.6

    32

    1.6±0.15

    18.0

    20.0

    1.069

    1.301

    1.133

    1.432

    40

    39.5

    40

    1.6±0.15

    19.0

    22.0

    1.36

    1.52



    /



    /

    50

    49.5

    50

    1.6±0.15

    19.0

    22.0

    1.71

    1.91

    60

    59.5

    60.3

    2.0±0.15


    /


    /

    2.40

    2.86

    75.5

    75

    75.55

    2.0±0.15

    3.25

    3.63

    88.5

    88

    88.5

    2.0±0.15

    3.83

    4.29

    114

    113.5

    114

    2.0±0.15

    4.98

    5.52


    BS4568-1970


    Size (mm)

    OD(mm)

    T(mm)

    Thread length (mm)

    Weight (KG/m)

    Min

    Max

    Min

    Max

    3/4’’

    18.9

    19.05

    1.65±0.10

    13.5

    14.3

    0.735±3%

    1’’

    25.25

    25.40

    1.65±0.15

    16.7

    17.5

    1.000±3%

    1-1/4’’

    31.60

    31.75

    1.65±0.15

    18.3

    19.1

    1.278±3%


    EMC(Electrical Metallic Tubing)

    Size

    ODinch/mm)

    Tinch/mm)

    tolerance

    Standard length (inch/mm)

    Weight(KG/pcs)

    inch

    mm

    size

    tolerance

    1/2"

    16

    0.706(17.93)

    ±0.005(0.13)

    0.042(1.07)

    ±0.05

    10"(3050)

    0.439

    3/4"

    21

    0.922(23.42)

    0.049(1.24)

    0.669

    1"

    27

    1.163(29.54)

    0.057(1.45)

    0.99

    1-1/4"

    35

    1.510(38.35)

    0.065(1.65)

    1.469

    1-1/2"

    41

    1.710(44.20)

    0.065(1.65)

    1.698

    2"

    53

    2.197(55.80)

    0.065(1.65)

    2.17

    2-1/2"

    63

    2.875(73.03)

    ±0.010(0.25)

    0.072(1.83)

    3.177

    3"

    78

    3.500(88.90)

    ±0.015(0.38)

    0.072(1.83)

    3.879

    4"

    103

    4.500(114.30)

    ±0.020(0.50)

    0.083(2.11)

    5.75


    IMC(Intermediate Metal Conduit)

    Product

    Size (inch)

    OD(mm)±0.3

    T(mm) ±0.15

    L(M) ±0.05

    W/pcs ±3%

    IMC

    1/2"

    20.7

    1.98

    3.05

    2.78

    3/4"

    26.1

    2.1

    3.05

    3.79

    1"

    32.8

    2.35

    3.05

    5.38

    1-1/4"

    41.6

    2.42

    3.05

    7.13

    1-1/2"

    47.8

    2.54

    3.05

    8.65

    2"

    59.9

    2.67

    3.05

    11.49


    Rigid Steel conduit(UL6-ANSI 80.1)


    Nominal Diamension Inch

    Outside Diameter Size

    Wall Thickness Size

    Length

    Weight

    Inch

    mm

    Inch

    mm

    FT

    mm

    KG/PC

    1/2"

    0.840

    21.3

    0.104

    2.6

    10

    3050

    3.72

    3/4"

    1.050

    26.7

    0.107

    2.7

    10

    3050

    4.94

    1"

    1.315

    33.4

    0.126

    3.2

    10

    3050

    7.3

    1-1/4"

    1.660

    42.2

    0.133

    3.4

    10

    3050

    9.89

    1-1/2"

    1.900

    48.3

    0.138

    3.5

    10

    3050

    11.93

    2"

    2.375

    60.3

    0.146

    3.7

    10

    3050

    15.87

    2-1/2"

    2.875

    73

    0.193

    4.9

    10

    3050

    23.35

    3"

    3.500

    88.9

    0.205

    5.2

    10

    3050

    32.97

    3-1/2"

    4.000

    101.6

    0.215

    5.5

    10

    3050

    39.91

    4"

    4.500

    114.3

    0.225

    5.7

    10

    3050

    46.71

    5'

    5.563

    141.3

    0.245

    6.2

    10

    3050

    63.49

    6"

    6.625

    168.3

    0.266

    6.8

    10

    3050

    83.45

    XK StrutChannel Series List

    Type

    W (mm)

    H (mm)

    T (mm)

    L(mm)

    XK4121P

    41

    21

    1.5-3

    3000

    XK4121S

    41

    21

    1.5-3

    3000

    XK4141P

    41

    41

    1.5-3

    3000

    XK4141S

    41

    41

    1.5-3

    3000

    XK4162P

    41

    62

    1.5-3

    3000

    XK4162S

    41

    62

    1.5-3

    3000

    XK4182S

    41

    82

    1.5-3

    3000

    XK4182P

    41

    82

    1.5-3

    3000

    Remark:
    *P-plain ; S-Slotted
    *Material:Q195
    *Length: 3000mm/pcs standard or be customized
    *Finish:Pre galvanized ; Hot Dip Galvanized; Powder Coated & Fire Proofed

  • Certificates
    Shanghai XK Construction Material Co.,Ltd
Product Catalog
